Endelig nogen som har lavet et fed 2×2 interface som ikke koster vandvittigt mange penge. Black Lion har trukket på alle deres erfaringer fra deres Audio-Mods, og taget alt det der bør opgraderes og opgraderet det fra starten!

PRis: 4.820,- inkl moms

SPECS

– 24bit, 192KHz USB C interface
– Bus Powered
– Macro MMC clocking
– Analog circuit design utilizing Nichicon, Vishay and Wima capacitors
– PG-i power filtering technology
– USB Class Compliant
– Revolution Software Suite

Mic Input
Input Impedance = 3KΩ (balanced)
Gain Range = 55dB
Frequency Response = 20Hz – 20KHz +/- 0.25dB
THD + N = .00098% (@12dB Gain)
Dynamic Range =  116dB (A-Weighted)
Crosstalk = < 100dB

Line Input
Input Impedance = 14KΩ (balanced)
Maximum Input = 20dBu
Gain Range = 55dB
Frequency Response = 20Hz – 20KHz +/- 0.25dB
THD + N = .0022% (Min Gain)
Dynamic Range = 126dB (A-Weighted)
Crosstalk = < 100dB

Line Outputs
Output Impedance = 95Ω (balanced)
Max Output Level = 12dBu
Frequency Response = 20Hz – 20KHz +/- 0.25dB
THD+N = .002% (@ +10dBu)
Dynamic Range = 106dB**

Instrument Input
Input Impedance = 1MΩ (unbalanced)
Gain Range = 55dB
Frequency Response = 20Hz – 20KHz +/- 0.25dB
THD + N = .00114% (@ 0dBu)
Dynamic Range = 103dB (A-Weighted)
Crosstalk = < 100dB

Headphone Outputs
Output Impedance = 2.5Ω
Maximum Signal Output = 9.3dBu
Frequency Response = 20Hz – 20KHz +/- 0.5dB
