100% analog device with +24dBu of headroom
True stereo tube “vari-mu” style compressor
High voltage tube operation
Interstage CARNHILL transformers
Input and output level control for maximum flexibility
Mix knob for parallel compression
THD – harmonic distortion with two modes (Medium & High)
SIDE CHAIN FILTERS – 3 high pass filters at 60,90 and 150 Hz
500 series and ng500 (e.g. _TITAN) series compatible
Total Recall and plugin control compatible with most DAWs.
Analog automation in DAW

PRis: Ring

SPECS

Frequency response: 10Hz-150kHz (-3dB)
THD+N: < 0.03% (1kHz,0dBu) – no compression
THD+N: >= 1% – at maximum compression level
Input impedance: 20kohm
Output impedance: < 100ohm
Max signal level: +24dBu
Crosstalk: < -80dB
THD (MID switch): 1%
THD (HIGH switch): 3%
Attack: 0.5, 1, 3, 10, 30, 50 (ms)
Release: 0.1, 0.3, 0.6, 0.9, 1.8, 3.6 (s)
SC Filter: 60, 90, 150 Hz
Power consumption: 190mA per rail
Dimensions: 76x133x158mm
