_PROMETHEUS is fully analog passive EQ with +24dBu of headroom. It features pultec-style warm sound with a lot of innovative improvements. Its modern approach to design allows instant recall of your classic vibe through very flexible plugin available in most common formats.
_PROMETHEUS as all ng500 products, integrates with your DAW environment via front panel USB socket or _TITAN chassis.
Passive equalizer (Pultec-style) design based on inductors.
– Low frequency boost/cut – 20, 30, 60, 100, 120, 250 Hz.
– High frequency boost – 2, 3, 4, 5, 8, 10, 12, 16 kHz.
– High frequency cut – 4, 8, 12, 20 KHZ.
Frequency response: 10Hz-150kHz (-2dB)
THD+N: < 0.01% (1kHz,0dBu)
Input impedance: 10kohm
Output impedance: < 100ohm
Max signal level: +24dBu
Crosstalk: < -100dB
THD (MID switch): 1%
THD (HIGH switch): 2,5%
Power consumption: 70mA per rail
